Did you get a hold of what a Digital Logic System is? Digital logic is the manipulation of binary values through printed circuit board technology that uses circuits and logic gates to construct the implementation of computer operations. A digital logic circuit or system is usually made up of combinational elements such as NAND and NOR gates and memory elements which may, for example, be discrete flip-flops or latches. Logic elements are the small electronic subsystems that perform the logic decisions of NOT, AND, OR, and so on, which are incorporated inside any piece of digital electronic equipment. The basic elements of digital circuits: MOSFET, gate the logic. Digital logic is fundamental in creating electronic devices. It is used to create circuits and logic gates, as well as to check computer chips. Knowledge of digital logic lends itself to many different computer technology design and engineering professions. All digital systems can be constructed by only three basic logic gates. These basic gates are called the AND gate, the OR gate, and the NOT gate.
